GF-800 Separated from one machine

Name：GF-800 Separated from one machine

Details
Machining being separated by mechanical sieving equipment is mainly the principle of crushing raw flesh, filtered and the separated meat and grains. The device utilizes poultry bones, and flesh of different physical characteristics (ie meat plasticity characteristics, and the bones will not have), through the material forward, crushing, extrusion and other means of pressure, combined with a narrow slit type separator filter with adjustable bone export and other devices, for poultry bones, and flesh of mechanical pressure screening, in order to achieve family separation operations.
Flesh separator is separated from poultry poultry byproduct value-added processing equipment, mainly used for processing chickens, ducks, geese and other poultry carcass or skeleton. Processing of the produce - meat, may be appropriate to add to the meatballs, sausages and other meat products, meat products can ensure the content, but also reduce the cost of production, waste of resources to effectively prevent protein; processing by-products - bone fragments, chondroitin can be used to extract, process puffed bone meal, animal feed and other production.

The main technical parameters:

Total power

21KW（28HP）

Screw motor power

15KW(20HP)

Screw speed

212转/分

Pump speed (adjustable)

15-93转/分

Hopper capacity pump power

5.6KW(7.5HP)

Hopper capacity

266升

Feeding capacity (raw material type varies)

Hourly up 1.3T-2.2T

Feed screw

Twin-screw

Drive assembly

Direct Drive

Machine size

2390x1200x2100mm

Raw materials (pounds)

Chicken skeleton

Whole chicken

Chicken bone

Chicken neck

Rabbit skeleton

Rate of meat (kg)

75

90

42

80

50
